Shenzhen Outdoor Specialized Display Equipment Co., Ltd. introduces its IP67 waterproof outdoor digital signage, designed specifically for all-weather advertising and information display in harsh outdoor environments. Featuring an IP67 fully sealed protection rating and a high-brightness output of 2500 nits, this product delivers clear and stable visual performance even under conditions involving rain, dust, and direct sunlight.

This IP67 outdoor waterproof display is widely utilized in various settings, including highway service areas, shopping mall entrances, parking lot EV charging stations, commercial district outdoor advertising spaces, and scenic area information kiosks. Its wall-mounted design conserves floor space while maintaining visibility at eye level. The full aluminum alloy housing offers both structural strength and efficient heat dissipation capabilities, making it suitable for use in coastal, tropical, and temperate climatic regions.

• Multi-Format Media Playback: MP4, AVI, JPEG, PNG, MP3
• Scheduled playlist management based on time, date, and day of the week
• Remote power on/off and brightness adjustment
• Automatic playback resumption after power recovery
• Split-screen display support
• Optional Touch Functionality (Projected Capacitive)

1. Mount the display to a vertical wall surface using the included VESA-standard mounting kit. Ensure the wall structure is capable of supporting the load (refer to the specifications listed above).
2. Connect the power cable via the waterproof cable gland; tighten the sealing nut to ensure a watertight seal.
3. Connect an Ethernet cable (RJ45) or configure Wi-Fi settings using the initial setup wizard.
4. Access the web-based management platform via a web browser to upload content and configure playback schedules.
5. During routine maintenance checks, verify that the silicone sealing strips are intact and the cable glands are securely tightened.

• Do not open the rear cover during rainy weather or in humid environments to prevent internal moisture damage.
• Prior to installation, ensure that the wall surface is flat and the structural support is secure.
• When cleaning, avoid directing high-pressure water jets directly at the cable entry points.
• The operating temperature must be maintained within the range of -20°C to 55°C. Customers in extremely cold regions are advised to contact us to order the version equipped with a built-in heater.
